Corral Bow Gates
Brand: Hi-Hog Farm & Ranch Equipment Ltd
The corral frame with built-in gate, also known as a bow gate, is commonly used for access and sorting in corral systems. This is a medium to heavy pressure frame & gate.
Features- All the gate tubing is 1 1/2” OD, 14-gauge
- The gates top, bottom, and end verticals are constructed of 1.9” OD, 14-gauge tubing
- The interior horizontal bars are constructed of 1.5” OD, 16-gauge tubing
- The inside opening between the top horizontal bars is 9 3/4”
- The opening between the bottom four horizontal bars is 7”
- The horizontals are reinforced with 1.25” x 3/16” flat bar welded on alternating faces of the gate
- The gate comes with a 7/8” plunger latch and striker plate
1 - 6 of 6 Part Numbers
365
- Gate Height - 60"
- Frame Height & Length - 8' long x 8' high
366
- Gate Height - 71.25"
- Frame Height & Length - 8' long x 8' high
375
- Gate Height - 60"
- Frame Height & Length - 10' long x 8' high
376
- Gate Height - 71.25"
- Frame Height & Length - 10' long x 8' high
385
- Gate Height - 60"
- Frame Height & Length - 12' long x 8' high
386
- Gate Height - 71.25"
- Frame Height & Length - 12' long x 8' high
1 - 6 of 6 Part Numbers
