74R2/74F2 Series Ball Valve
Brand: Belgaum Aqua Valves Pvt. Ltd.
These are high performance ball valves in Class 150 – 2pc construction. With the floating seal design, the ball diameter is greatest in the close position and the seat is free to expand on closing and contract on opening.
This Continuous ball to seat contract ensures proper adjustment and continual sealing. Since the seat is allowed to float in open position, fluids and debris do not accumulate around and behind the seat.
This results in self-Cleaning action, reduced wear and smoother operation. These Valves are with built in antistatic features & double seal design and can be offered in soft Seated as well as metal Seated design.
Codes & Standards Conformity:
General design & Manufacturing: BS EN ISO -17292/API-608/ API-6D
Valve Dimensions: ANSI B 16, 10 / B 16.5
Valve Inspection & Testing : EN 12266-1
Hydro Shell: 31 kg/sq.cm
Seat Test: 23 kg/ sq.cm
Air Seat: 7 Kg/ sq.cm
Special Features: Fire safe to API-607/6FA Metal to Metal Seat
Features- Maintenance free live loaded double sealing stem packing ensures high cycle’s life and positive sealing.
- Blow-out Proof Stem
- ISO5211 Mounting Pad Allows for mounting of actuator
Specifications
Valve Type
- Floating Design Ball Valve
Body Type
- 2pc / 3pc
End Connection
- Flanged
Size Range
- 15NB to 300NB
Pressure Rating
- Class 150
Seat Leakage
- Class VI- soft seat. Class V-Metal seat
Conformity to Codes & Standards
- General Design: BS EN ISO -17292/API-608/ API-6D
- Valve Dimensions: ANSI B 16, 10 / B 16.5
- Valve inspection & testing : EN 12266-1
- Special Features: Fire safe to API-607/6FA Metal to Metal Seat
