S.T Series – Interchangeable Temperature Humidity Probes

Brand: Delta OHM S.R.L.
Add Product to My Catalog

Interchangeable temperature and humidity probes with SICRAM 2 module and cable for the HD2717T... and the HD2817T... transmitters series.

The probes are supplied with filter P7 as standard. For temperatures up to 150 °C, we recommend the use of probes with stainless steel (AISI 304) stem.

All stainless steel probes can be optionally supplied for temperatures upto 180 °C with filter P6. This option (S.TCHT) has to be requested upon ordering the probe.

1 - 12 of 22 Part Numbers
S.TC1.10
S.TC1.10
Probe with cable. Stem length 135 mm, cable length 10 m. AISI 304 made, P7 filter, max 150°C.
S.TC1.10HT
S.TC1.10HT
Probe with cable. Stem length 135 mm, cable length 10 m. AISI 304 made, P6 filter, max 180°C.
S.TC1.10P
S.TC1.10P
Probe with cable. Stem length 135 mm, cable length 10 m. PBT made.
S.TC1.2
S.TC1.2
Probe with cable. Stem length 135 mm, cable length 2 m. AISI 304 made, P7 filter, max 150°C.
S.TC1.2HT
S.TC1.2HT
Probe with cable. Stem length 135 mm, cable length 2 m. AISI 304 made, P6 filter, max 180°C.
S.TC1.2P
S.TC1.2P
Probe with cable. Stem length 135 mm, cable length 2 m. PBT made.
S.TC1.5
S.TC1.5
Probe with cable. Stem length 135 mm, cable length 5 m. AISI 304 made, P7 filter, max 150°C.
S.TC1.5HT
S.TC1.5HT
Probe with cable. Stem length 135 mm, cable length 5 m. AISI 304 made, P6 filter, max 180°C.
S.TC1.5P
S.TC1.5P
Probe with cable. Stem length 135 mm, cable length 5 m. PBT made.
S.TC2.10
S.TC2.10
Probe with cable. Stem length 335 mm, cable length 10 m. AISI 304 made, P7 filter, max 150°C.
S.TC2.10HT
S.TC2.10HT
Probe with cable. Stem length 335 mm, cable length 10 m. AISI 304 made, P6 filter, max 180°C.
S.TC2.10P
S.TC2.10P
Probe with cable. Stem length 335 mm, cable length 10 m. PBT made.
1 - 12 of 22 Part Numbers

Specifications

Brand

Temperature Inputs

  • Sensor: Pt100
  • Measuring range: -50° to 200° C
  • Resolution: 0.1° C
  • S.TC2.480.2 / S.481.2 Temperature Measuring range: -40° to+60° C

Humidity Inputs

  • Sensor: Capacitive
  • Response time: 3 min with filter
  • Resolution: 0.1 % RH

Humidity Accuracy

  • ± 1.5 % RH (0…90 % RH)
  • ± 2.0 % RH (elsewhere)
  • @ T=15° to 35° C
  • ± (1.5+1.5 % of the measured value)
  • % RH @ T = remaining range

Accuracy of the Calculated Physical Quantities

  • Accuracy of the Dew point @ T = 20° C
  • ± 2° C DP (-40° to -20° C DP)
  • ± 1.5° C DP (-20° to 0° C DP)
  • ± 1° C DP (0° to +20° C DP)

Documentation

Data Sheets
