SCT Cooling Tower
Brand: Winters Instruments
Features
- Perforated case c/w spiral tubing protects pressure gauges, switches and transmitters.
- Used where the process media temperature exceeds the rating of the instrument
- For process media temperatures up to 570°F. Can reduce the media temperature by as much as 500°F*
- RoHS compliant
1 - 4 of 4 Part Numbers
SCT-400
- Maximum Process Temperature - 300° C (570° F)
- Connection - 1/4" NPTM x 1/4" NPTF
SCT-500
- Maximum Process Temperature - 300° C (570° F)
- Connection - 1/2" NPTM x 1/2" NPTF
SCT-600
- Maximum Process Temperature - 500° C (932° F)
- Connection - 1/4" NPTM x 1/4" NPTF
SCT-700
- Maximum Process Temperature - 500° C (932° F)
- Connection - 1/2" NPTM x 1/2" NPTF
1 - 4 of 4 Part Numbers
Specifications
Brand
Approvals & Certifications
- CRN - Canadian Registration Number
- RoHS
Materials of Construction
- Socket: 316L Stainless Steel
- Tube: 316 Stainless Steel (SST)
NPT Connection
- 1/2" NPT Female
- 1/2" NPT Male
- 1/4" NPT Female
- 1/4" NPT Male
Operating Pressure
- Maximum
Process Temperature
- Maximum
- Clean (No Particulate) Media, Gases
- When Used With a Diaphragm Seal, the Pressure Rating of the Diaphragm Seal must be Acknowledged
- Extreme High Temperature Installations
- Used in Oil & Gas Installations, Chemical Processing and Mining
