A-T Controls 3-Way General Purpose Automated Ball Valve, 38 Series

38 Series Automated Ball Valve

Brand: A-T Controls, Inc
Add Product to My Catalog

A-T Controls 3-Way General Purpose Automated Ball Valve, 38 Series
This investment cast 3-way valve can be an economical option for flow patterns that normally require multiple 2-way valves.

Available in L or T port configurations, this valve is excellent for diverting flow within control loop processes.
Features
  • Design: 3-Way General Purpose Automated Valve
  • Size: 1/4" to 2"
  • Port: Reduced
  • Direct Mount: No
  • Pyramidal Stem Packing: No
  • Materials of Construction
    • Body: 316 Stainless Steel
    • Trim: 316 Stainless Steel
    • Available Seats: RTFE
  • End Connections: Threaded Ends
  • Maximum Pressure Rating: 1,000 psi
  • Actuator Type
    • Pneumatic: Double Acting or Spring Return
    • Electric: On/Off or Modulating

1 - 12 of 741 Part Numbers
38-TX-0038/2R2S-XX-LT-L
38-TX-0038/2R2S-XX-LT-L
A-T CONTROLS Series 38 Automated Ball Valve, 3-Way Regular Port, 316 SST, 3/8" NPT, RTFE, 2R40SR Pneumatic Actuator, Spring Return, L-Port, Low Temperature
  • Design: Threaded General Purpose 3-way
  • Size: 3/8" NPT
  • Port: Reduced
  • Materials of Construction:
    • Body: 316 Stainless Steel
    • Trim: 316 Stainless Steel
    • Available Seats: Reinforced TFE Seats

  • End Connections: Threaded Ends
  • Maximum Pressure Rating: 1000 psi
  • Actuator-Pneumatic: 400 In-Lbs. Spring Return
  • Options: L - Port, Low Temperature
38-TX-025/2R2D-AA-L
38-TX-025/2R2D-AA-L
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 4 Solenoid
  • Limit Switch - NEMA 4 Limit Switch 2 SPDT
  • Port Arrangement - L Arrangement
38-TX-025/2R2D-AA-T
38-TX-025/2R2D-AA-T
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 4 Solenoid
  • Limit Switch - NEMA 4 Limit Switch 2 SPDT
  • Port Arrangement - T Arrangement
38-TX-025/2R2D-AB-L
38-TX-025/2R2D-AB-L
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 4 Solenoid
  • Limit Switch - NEMA 7 Limit Switch 2 SPDT
  • Port Arrangement - L Arrangement
38-TX-025/2R2D-AB-T
38-TX-025/2R2D-AB-T
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 4 Solenoid
  • Limit Switch - NEMA 7 Limit Switch 2 SPDT
  • Port Arrangement - T Arrangement
38-TX-025/2R2D-AC-L
38-TX-025/2R2D-AC-L
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 4 Solenoid
  • Limit Switch - Intrinsically Safe Limit Switch
  • Port Arrangement - L Arrangement
38-TX-025/2R2D-AC-T
38-TX-025/2R2D-AC-T
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 4 Solenoid
  • Limit Switch - Intrinsically Safe Limit Switch
  • Port Arrangement - T Arrangement
38-TX-025/2R2D-AX-L
38-TX-025/2R2D-AX-L
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 4 Solenoid
  • Limit Switch - None Selected
  • Port Arrangement - L Arrangement
38-TX-025/2R2D-AX-T
38-TX-025/2R2D-AX-T
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 4 Solenoid
  • Limit Switch - None Selected
  • Port Arrangement - T Arrangement
38-TX-025/2R2D-BA-L
38-TX-025/2R2D-BA-L
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 7 Solenoid
  • Limit Switch - NEMA 4 Limit Switch 2 SPDT
  • Port Arrangement - L Arrangement
38-TX-025/2R2D-BA-T
38-TX-025/2R2D-BA-T
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 7 Solenoid
  • Limit Switch - NEMA 4 Limit Switch 2 SPDT
  • Port Arrangement - T Arrangement
38-TX-025/2R2D-BB-L
38-TX-025/2R2D-BB-L
  • Enclosure Material - Stainless Steel Body
  • Valve Size - 1/4" NPT
  • End Connection - Threaded Ends
  • Seat Material - RTFE - Reinforced Teflon
  • Actuator Type - Double-Acting
  • Actuator Size - 60 psi, 400 inch-Pounds
  • Solenoid - NEMA 7 Solenoid
  • Limit Switch - NEMA 7 Limit Switch 2 SPDT
  • Port Arrangement - L Arrangement
1 - 12 of 741 Part Numbers

View_Details

Specifications

Brand

Direct Mount

  • No

Enclosure, Body Material

  • 316 Stainless Steel

NPT Connection

  • 1" NPT Female
  • 1/2" NPT Female
  • 1/4" NPT Female
  • 1-1/2" NPT Female
  • 1-1/4" NPT Female
  • 2" NPT Female
  • 3/4" NPT Female
  • 3/8" NPT Female

Options

  • Intrinsically Safe Solenoid & Limit Switches
  • L or T Ports
  • NEMA 4 Solenoid 120 Vac & Switches
  • NEMA 7 Solenoid 120 Vac & Switches

Port

  • Reduced (Standard, Regular)

Pressure Rating

  • 1000 psi

Pyramidal Stem Packing

  • No

Seat / Seal Material

  • RTFE (Reinforced Teflon)

TA-Luft Certified

  • No

Trim Material

  • 316 Stainless Steel

Valve Type

  • Automated
