GP:50 WECO® "Hammer" Union Pressure Transmitter, Model 270

Model 270 WECO® Pressure Transmitter

Brand: GP:50 New York Ltd
Add Product to My Catalog

GP:50 WECO® "Hammer" Union Pressure Transmitter, Model 270 GP:50 WECO® "Hammer" Union Pressure Transmitter, Model 270 GP:50 WECO® "Hammer" Union Pressure Transmitter, Model 270
Features
  • Reduced zero offset due to installation
  • High-accuracy option of ±0.10% FSO
  • Corrosion resistant, high strength fasteners eliminate housing breakage
  • Hazardous location approvals
  •  0 to 1000 thru 0 to 20K PSI (69 thru 1,379 BAR)
  • Compatible with 2” 1502, 2002, 2202, and 602 wing union fittings
  • Output Signal: 0 to 5 Vdc
  • Supply Voltage: 9 to 36 Vdc
  • Pressure Range: 0 to 20,000 psi (69 to 1,379 bar, 0 to 137,895 kPa)
  • Burst Pressure: 3 times FSO
  • Proof Pressure: 1.5 times FSO or 22,500 psi whichever is less
  • Electrical Connections: PTO2E-10-6P
  • Process Connection: WECO 2" - 1502, 2002/2202 or 602
  • Temperature Range:
    • Operating: -45° to 85°C (-50° to 190°F)
    • Compensated: -40° to 80°C (-40° to 180°F)
    • Effect on Zero/Span: 1% Full Scale Output at 100°F
  • Static Accuracy:
    • Standard: ≤± 0.25% Full Scale Output
    • Improved: ≤± 0.10% Full Scale Output
  • Materials of Construction:
    • Housing: 300 Series Stainless Steel
    • Sensor :17-4 PH Stainless Steel

Specifications

Brand

Accuracy

  • ≤ ± 0.10 % of FSO
  • ≤ ± 0.25 % of FSO

Compensated Temperature

  • -40° to 80° C (-40° to 176° F)

Electrical Connectors

  • Bendix PT02E-10-6P

Enclosure, Body Material

  • 300 Stainless Steel

Environmental Protection

  • IP67

Input Signal

  • 8 mA Nominal

Operating Temperature

  • -45° to 85° C (-50° to 190° F)

Output

  • 0-5 Vdc

Pressure Range

  • bar: 69 to 1,379
  • kPa: 0 to 137,895
  • psi: 0 to 20,000

Proof Pressure

  • 1.5 x Pressure Range or psi: 22,500 (bar: 1,551, kPa: 155,132), whichever is less

Resistance

  • 10,000 ohms

Shunt Calibration

  • 100 % of FSO ± 0.2 % Shorting E + F

Span & Zero Effect

  • < ± 1.0 % of FSO 38° C (100° F)

Supply Voltage

  • 9 to 36 Vdc

Wetted Materials

  • 630 Stainless Steel

  • Fracking, Cementing, Coil Tubing and Acidizing
  • Mud pumps / Measure While Drilling
  • Choke and Kill Manifolds
  • Standpipe Pressure
  • Wellhead Measurement
